“Compact Punch, All-Weather Performance: IP66 Dual 260W Pixel Wash”
Don’t let the compact size fool you. This fixture is a high-output solution designed for the rigors of the road. By combining two high-intensity 260W RGBW main engines with a vibrant dual-layer Aura effect, it delivers a unique visual signature that stands out on any stage.
The 2.3° to 17° zoom provides incredible flexibility, functioning as both a high-impact beam and a deep-saturation wash light. Built with a rugged IP66-rated housing, it ensures total reliability in the most extreme outdoor conditions. With Linear CTO and 16-bit dimming, it offers the precision required for high-end broadcast and theatrical use, all while remaining light enough for rapid deployment.
Power: AC100-240V, 50/60Hz;
Power Consumption: 600W;
Light Source: 2x260W RGBW LED, 2x36x0.5W RGB LED;
Beam Angle: 2.3°-17°;
Movement:
Pan: 540°;
Tilt: 250°;
Accuracy: 16-bit;
Correction: Automatic position correction after step loss;
Control:
Channel Mode: 22/43/47/51/57CH, 23+14CH(DMX+Art Net);
Protocol: DMX512 / RDM / Art-Net(optional) / sACN(optional);
Software Upgrade: Supports firmware update via DMX;
Structure:
Display: Reversible 1.8-inch TFT;
Data Connector: 3-pin XLR socket(5-pin optional) / RJ45 optional;
Power Connector: PowerCON in/ out, 16A in/ out(optional)
Protection Rate: IP66
Features:
2 independent main light heads;
36 RGB LEDs around each head ring;
Smooth 0–100% dimming with various strobe effects at different speeds;
4 dimming curves;
Linear CTO color temperature adjustment from 2300K to 10000K;
Excellent color macro effects;
Motorized zoom system;
Temperature sensor detection with intelligent light source power adjustment and smart fan speed control.
Environment Temperature: operates in ambient temperatures from -10°C to 40°C.
Installation: Can be inverted suspended, horizontally mounted on truss, or placed on a flat horizontal surface. Always use and install a safety cable as a safety precaution.
Dimension: 499.8*188*439.2mm;
NET Weight: 14KG;
