49x20W LED Matrix Zoom

Unlock studio-grade precision with this 49x20W RGBW LED fixture, engineered for theaters and concert halls.
Boasting 4°–46° beam control, 65536-level dimming, and infinite vertical tilt rotation (0.0034° accuracy via photoelectric reset), it crafts cinematic effects from subtle gradients to 25Hz strobes.

Pro Features:

Artnet Integration – Sync with 229 DMX channels for complex shows.
Energy Smart – 760W±5% output + 26W standby mode (PF≥0.95).
Macro Mastery – Preset color/effect combos + single-LED control.
Tour-Ready – 22.5kg lightweight + 2-in-1 flight case (87.8kg).

Ideal For: Indoor concerts, theater productions, and installations needing pixel-level control, silent cooling, and rapid scene switching.

Beyond 4920Z

49x20W LED Matrix Zoom

Light Source: 49 x 20W 4in1 RGBW LED

LED Lifetime: ≥ 50000H

Power Voltage: AC100-240V， 50- 60Hz

Power Consumption: 760W±5W

Beam Angle: 4°~46°

Control Modes: DMX512/ Auto/ Sound/ Master/ Manual/ RDM/ ArtNet（optional）

DMX Channel: 22/ 25/ 33/ 229/ 206 Channel

Protection Rating: IP20

Display: 1.8°TFT Color Display

Data In/Out Socket: 3-pin & 5-pin XLR sockets

Power Socket: Power-Con in/ out

Housing Material: ABS High temperature resistant plastics

Pan: 540°,Accuracy 2.11°/step, fine-tuning accuracy: 0.008°

Tilt: 270°,Accuracy 0.86°/step, fine-tuning accuracy: 0.0034°

Photoelectric reset system: Tilt infinite rotation; photoelectric reset system

Pan/Tilt Resolution: Automatically correct pan/tilt position

MAX. Connection: 4 units（240V，50Hz） 2.5mm² power cable; 2 units（100V，60Hz） 2.5mm² power cable

Dimension: 477 mm x 272 mm x 579.5 mm

Net Weight: 23.35kg

Carton Package: 590mm*590mm*445mm 1in1 GW: 27.2kg

Flight Case: 740mm*540mm*775mm 2in1 GW: 80.3kg

Features: Full light range dimming, 65536-level dimming accuracy. Fast strobe 1- 25Hz.LED single control, Preset multiple color macro, Preset multiple effect macro

Configuration: Signal cable 1pc; Power cable 1pc; Manual 1pc;
